| Modular |
Full Modular |
| Model |
RSC00-AFBAG1-XX |
| PFC |
Active PFC (>0.9 typical) |
| ATX Version |
Intel Form Factor ATX 12V V2.31 |
| Dimensions (L x W x H) |
190 x 150 x 86 mm |
| Operation Voltage |
100-240Vac |
| Input Current |
15-7.5A |
| Input Frequency |
50-60Hz |
| Power Good Signal |
100 - 500 ms |
| Hold Up Time |
>17ms |
| Efficiency |
93% Typically |
| MTBF |
>100,000 Hours |
| Protections |
OVP, UVP, OPP, OTP, OCP, SCP |
| Output Capacity |
1200W |
| Operating Temperature |
0-40°C |
| Regulatory |
CE, TUV, TUV-SUDNRTL, FCC, EAC, CCC, BSMI, RCM, KC |
| Fan Size |
Silent FDB 135mm |
| Certification |
80 Plus Platinum |
| MB 20+4 Pin Connectors |
1 |
| CPU 12V 4+4 Pin Connectors |
2 |
| PCI-e 6+2 Pin Connectors |
12 |
| SATA Connectors |
12 |
| Peripheral 4-Pin Connectors |
9 |
| FDD Cable 4-Pin Connectors |
1 |
