Split Hydro Miner Cooling Kit - 6Way - 50Kw
In Stock CPT
Hydro Cooling Kit MG-6W50
High-Efficiency Home Hydro Cooling with EC Fan and Water Curtain Technology
The MG-5W50 is a purpose-built hydro cooling solution designed for home and small-scale mining deployments. While most residential hydro cooling systems rely on fixed-speed fans and basic radiator setups, the MG-6W50 stands out by incorporating both EC automatic fan control and an optional water curtain cooling stage—two features rarely found in competing systems.
This intelligent dual-stage cooling approach ensures quiet operation in cooler conditions and powerful heat rejection when temperatures rise, maintaining consistent thermal performance even in high ambient climates.
Built to support up to 6 Antminer Hydro miners, the MG-6W50 offers industrial-grade cooling in a compact footprint optimized for residential and garage installations. Its closed-loop deionized water system enhances long-term reliability by preventing scale formation and corrosion inside the cooling circuit.
⸻
Technical Specifications and Features
• Cooling Capacity: Supports up to 6 Antminer Hydro miners
• Cooling System Type: Closed-loop deionized water circulation
EC Fan System:
- Automatically adjusts RPM based on water temperature
- Built in fan controller for setting auto parameters
- Enables quiet operation during low ambient conditions
- Power Input: 3-Phase 380–415V, 50/60Hz
- Max Power Consumption: ~1.8 kWh
- Maximum Airflow: ~20,000 CFM
- Fan Diameter: 970 mm
Water Curtain Cooling (Optional Use):
- Adds an evaporative cooling stage for additional heat dissipation
- Connects to standard water supply
- Auto Regulated Reservoir: Float valve maintains water level automatically
Design Format: Compact, space-efficient layout suitable for residential environments
Noise Profile: Optimized for home or garage installations through EC fan modulation
Built for Miners Who Need Real Performance — Without Industrial Noise or Bulk
The MG-6W50 is engineered for users who want more than just a fan and radiator. With temperature-adaptive EC fan control and optional water curtain cooling, it delivers a level of efficiency, noise reduction, and hot-weather resilience that standard cooling cabinets cannot match.
| MG-6W50 Cabinet Specifications | |
|---|---|
| Model | MG-6W50 |
| Heat Dissipation Capacity | 35 kW |
| Miner Support Capacity | Up to 6 × Antminer S19 / S21 Hydro |
| Circulation Mode | Single-loop |
| Dimensions (Cabinet) | 800 mm (L) × 790 mm (W) × 1450 mm (H) |
| Weight (Cabinet) | 149 kg |
| Cooling Fluid | Pure water / Treated soft water with antifreeze + corrosion inhibitor |
| Max Inlet / Outlet Temp | 50 °C (Inlet) / 60 °C (Outlet) |
| External Cooling | Dry cooler (included) |
| Required Flow Rate | 2 m³/h |
| Max Power Load (Thermal) | 35 kW |
| Input Voltage | 3-Phase, 380–480 V, 50/60 Hz |
| Output Voltage | 3-Phase, 380–480 V, 50/60 Hz |
| Ambient Operating Range | −25 °C to +45 °C |
| Design Pressure | 0.3 MPa |
| Included Components | High-quality water pump, stainless fittings, EPDM hose set, quick-connect couplings |
| MG-6W35 Cooling Tower Specifications | |
|---|---|
| Dimensions (Cooler) | 1100 mm (L) × 1100 mm (W) × 1400 mm (H) |
| Weight (Cooler) | 170 kg |
| Cooling Capacity | 35 kW |
| Circulation Mode | Single-loop |
| Input Voltage | 3-Phase, 380–415 V, 50/60 Hz |
| Output Voltage | 3-Phase, 380–415 V, 50/60 Hz |
| Cooling Medium | Pure water / Treated soft water with antifreeze + corrosion inhibitor |
| Max Inlet / Outlet Temp | 40 °C (Inlet) / 50 °C (Outlet) |
| Fluid Flow Rate (Tower) | 20 m³/h |
| Ambient Operating Range | −25 °C to +45 °C |
| Design Pressure | 0.3 MPa |
